SAFETY NET SEWING MACHINE
1. Basic information:
Device name: SAFETY NET SEWING MACHINE
Model: RD-FR-20.
Type : Semi-Automatic Machine
Dimension:1.3*0.9*1.3m, 500kgs.
Warranty: Two years for machine motor under normal use, except wearing parts.
Spare parts: tool( scissors/tweezers...) :1box;stitch:2bag(10pcs/bag);mold:1pcs.
2. Product detail
①It is multi functional machine, two functions, first hemming with sewing machine, then punch eyelet automatically.
②It is mainly used for safety net processing.
③All the machine is controlled by PLC and touch screen, easy to operate.
④edge hemming and eyelet distance can be adjusted if needed.
Product Picture
Sewing machine
• 220V/60HZ,2KW.
•chain sewing machine with double stitch,stitch width:2.5cm(1inch),stitch length:1.6cm( can adjusted according to required).
• speed: depending on eyelet distance.
(distance:30cm, speed:1000r/m around; distance 50 to 60cm, 1400r/m around.)
Eyelet machine
• 220V/60HZ,1.5KW.
• one machine with one fixed size eyelet, no change.(size depending on required).
• Pneumatic type, air pressure 0.7 to 0.8Mpa.
Speed: if eyelet distance 30cm, about 15meter/min.
Cutting machine
• controlled by Siemens PLC and touch screen, easy to operate and precise control
• using servo motor to control operating,making sure stable and precise running.
• length can be set up denpending on required.
Our Factory
